TP1 Radio MINI

tp1_radio_mini-v0.3

A smaller TP1-style radio with the knob on top, reusing the full-size mounts.

conceptv0.3
first mini assembly; bench fixes applied (USB female moved below the speaker, straps removed, larger anti-warp chamfers, USB-screw countersinks)

TP1 mini — full assembly (with hardware)693 KB

drag to orbit · scroll or pinch to zoom
composed of: tp1 radio mini body, hw speaker, hw carrier, hw encoder, hw knob, tp1 radio mini lid — all at v0.x

TP1 mini — assembly (closed)342 KB

drag to orbit · scroll or pinch to zoom
composed of: tp1 radio mini body, tp1 radio mini lid — all at v0.x

TP1 mini — body147 KB

drag to orbit · scroll or pinch to zoom

TP1 mini — rear lid194 KB

drag to orbit · scroll or pinch to zoom

Specs & BOM

ParameterValueUnit
Envelope82 × 150 × 42mm

CAD-based product images

AI-finished images of rendered CAD geometry; not a physical print or fit test.
