CAD-based product images
AI-finished images of rendered CAD geometry; not a physical print or fit test.
6 phases

OK-1
Envelope 52 × 50 × 25 mm (v6.1: depth 24 → 25).
activev6.1

S3 Zero OLED Enclosure
With MCU centered behind the OLED, 5 of 9 MCU pin X positions land inside the OLED PCB's XY footprint and both pin rows are within the OLED PCB's Y range.
supersededv5

S3 Zero OLED Enclosure
v4 adds a visual / industrial-design pass over v3's functional refinements.
supersededv4

S3 Zero OLED Enclosure
v3 refines v2 with debug/UX features that survived a print-fit pass: BOOT and RESET paperclip-access holes through the rear lid, an encoder anti-rotation locating hole on the right wall, a Ø2.5 light-pipe over the onboard WS2812 LED, six…
supersededv3

S3 Zero OLED Enclosure
3D + screenshots: https://cadgent-preview.pages.dev/s3zero_oled_enc_v2/
supersededv2

S3 Zero OLED Enclosure
Interactive 3D + screenshots hosted on Cloudflare Pages: https://cadgent-preview.pages.dev/
supersededv1
